The inside surface of our hose is smooth and it will make cleaning of hose very easy after every use.
As the hose is clear transparent, you can make sure that there is no left over particle of dirt on the inside wall after cleaning.
Visible flow.
Good resistance to milk and other food products.
Light in weight.
Tough enough to resist distortion under impact and crush loads during service.
Resistance to absolute vacuum assures ideal suitability for suction and delivery application.
| Nominal Size | Diameter | Pressure ( at 30° c ) | |||||
| Inches | mm | ID (mm) | OD (mm) | Bending Radius (mm) | Working Pressure (kg/CM2) |
Bursting kg/CM2 |
Standard Lengths (mtrs.) |
| 1 | 25 | 25.4* | 30.0** | 55 | 7.0 | 20.0 | 30 |
| 1¼ | 30 | 31.8* | 36.8** | 75 | 6.5 | 20.0 | 30 |
| 1½ | 40 | 38.0* | 43.3** | 95 | 5.0 | 16.0 | 30 |
| 2 | 50 | 50.8* | 57.8*** | 122 | 4.0 | 16.0 | 30 |
| 2½ | 65 | 63.5* | 72.0*** | 160 | 4.0 | 16.0 | 30 |
| 3 | 75 | 76.2* | 85.0*** | 272 | 3.5 | 15.0 | 30 |
| 3 | 100 | 101.2* | 112.2**** | 290 | 3.5 | 11.0 | 30 |
Recommended maximum working temperature : 60/70° C
Variation in ID/OD : { * = ± 0.5 } { ** = ± 1.0 } { *** = ± 1.5 } { **** = ± 2.0 }
